Jomox goes modular...

We'd like to introduce our new euro rack drum module series:

Continuing the proven Jomox analog drum desktop modules, we have decided to expand into the 19” euro rack market while keeping the tradition of our storeable analog sound production. To achieve this, we had to develop a complete new analog control system for our circuitries inside these modules.

We'd like to make these euro rack products interesting for both live drummers and modular people. Therefore, a CV/Gate control and trigger inputs for drumpad pickups are available.

For regular modular use, analog routable CV inputs and an analog output are accessible via 3.5mm jacks. The Gate can be configured as 0-5V, 0-15V, inversed or s-trigger.

Everything is storeable and can be recalled via encoder klick from 128 presets. But for the analog feel of modular, eight potentiometers give you the fine and precise editing of the most important parameters without stepping through menus.

E-Drummers can create complete E-drum setups, because there is an internal Jomox analog connection bus with a fast digital link which can do a submix and an FX send mix from each module hooked up to the bus.

Over this system bus you won't need to use the audio outputs but instead you have a programmable bus system that can link to future master, sequencer and mixing or effects modules - which can take control over the single modules.

This makes the whole modular setup recallable and storeable from a center module like a drum machine.
You certainly can't imagine a live drummer who may tweak the knobs of the pure analog modular system prior to each song he wants to perform;)

Also, to link the ModBase modules to our other products, they all have a Midi interface on the rear that can be wired within the rack case and being cascaded from one module to another.
The menu selection is paged by two-colored LEDs for both sides of the menu.

ModBase 09 Bass Drum Module and Mod.Brane 11 Percussion Module are supposed to be available in Summer 2013. More modules are yet to come.
